Dell P97F Service Manual

Steps
1. Align and place the system board on the palm-rest and keyboard assembly.
2. Replace the two screws (M2x2) that secures the system board to the palm-rest and keyboard assembly.
3. Connect the display cable on to the connector on the system board.
4. Connect the power-adapter cable on to the connector on the system board.
54
Removing and installing components

Dell P97F Specifications

General

Brand	Dell
Model	P97F
Category	Laptop
Language	English
