Dell Precision 3430 Small Form Factor User Manual

8 Install the:
a
Front bezel
b Side cover
9 Follow the procedure in After working inside your computer.
Optical drive
Removing the optical drive
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a
Side cover
b Front bezel
3 To remove the optical drive:
a Disconnect the hard drive data cable and power cable from the connectors on the hard drive [1, 2].
b Slide the release tab to unlock the hard drive and optical module [3].
c Lift the hard drive and optical module [4].
Removing and Installing components 33
