Installing the system fan
1 To replace the system fan:
a Align and place the system fan in the system chassis [1].
b Pass the grommets through the chassis and slide outward along the groove to secure it in place [2,3].
c Connect the system fan cable to the system board [4].
72 Removing and Installing components
