2 Install the:
a
Hard drive and optical drive module
b Front bezel
c Side cover
3 Follow the procedure in After working inside your computer.
Power supply unit
Removing power supply unit or PSU
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a
Side cover
b Front bezel
c Hard drive and optical drive module
3 To release the PSU:
a Disconnect the CPU power cable from the connector on the system board [1].
Removing and Installing components 65
