Dell Precision 3430 Small Form Factor User Manual

3 Install the:
a
Hard drive and optical drive module
b Front bezel
c Side cover
4 Follow the procedure in After working inside your computer.
Processor
Removing processor
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a
Side cover
b Front bezel
c Hard drive and optical drive module
d Heat sink and heat sink fan
3 To remove the processor:
a Release the socket lever by pushing the lever down and out from under the tab on the processor shield [1].
b Lift the lever upward and lift the processor shield [2].
c Lift the processor out of the socket [3].
Removing and Installing components 47
