Dell Precision 3430 Small Form Factor User Manual

b Lift and pull out the Intel Optane card from its connector on the system board [2].
c Peel the thermal pad [3].
Installing the Intel Optane card
1 Place the thermal pad into the slot on the system board [1].
2 Insert the Intel Optane card into the card slot on the system board [2].
3 Replace the single (M2 x 3.5) screw that secures the Intel Optane card to the system board [3].
52 Removing and Installing components
