Dell Precision 3430 Small Form Factor - Page 68

3 Connect the power cable to the connector on the system board [1].
4 Route the system power cable through the retention clips [2].
5 Route the CPU power cable through the retention clips [3].
6 Connect the CPU power cable to the connector on the system board [4].
68 Removing and Installing components
