Dell Precision 490 Desktop - Page 134


6. Ensure that all connectors are properly cabled and firmly seated.

7. Rotate the hard-drive carrier back into place (see Rotating the Hard-Drive Carrier Back into the Computer).

8. Replace the computer cover (see Replacing the Computer Cover).

9. Connect the computer and devices to electrical outlets, and turn them on.
Back to Contents Page

1
speaker (optional)
4
speaker cable
2
speaker slots with tabs (3)
5
speaker connector on system board
3
latch release tab


NOTICE: To connect a network cable, first plug the cable into the network port or device and then plug it into the computer.
