Processor
DellPrecision™Workstation490User'sGuide
Removing the Processor
Installing the Processor
Removing the Processor
1. Follow the procedures in Before You Begin.
2. Remove the computer cover (see Removing the Computer Cover).
3. Rotate the hard-drive carrier out of the computer (see Rotating the Hard-Drive Carrier Out of the Computer).
4. Rotate the processor access door to its open position.
5. Loosen the four captive screws on the sides of the heat-sink assembly.
6. Lift to remove the heat-sink assembly from the computer.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before opening the cover.
NOTICE: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of your
computer's electronic components. You can do so by touching an unpainted metal surface on the computer.
NOTE: To loosen the four captive screws on the sides of the heat-sink assembly, you need a long Phillips screwdriver.
CAUTION: The heat-sink assembly may become very hot during normal operation. Ensure that it has had sufficient time to cool before you touch
it.
