Replacing the System Board
1. Transfer components from the existing system board to the replacement system board:
a. Remove the memory modules and install them on the replacement board. See Memory for more information.
b. Remove the processor from the existing system board and transfer the processor to the replacement system board. See Processor for more
information.
2. Set the jumpers on the replacement system board so that they are identical to the ones on the existing board (see System Board Components.)
3. Orient the replacement board by aligning the screw holes in the board with the corresponding holes in the computer chassis.
4. Screw in the 9 screws that attach the system board.
5. Replace the heat sink assembly and tighten the four captive screws to secure it to the system board.
6. Replace any components and cables that you removed from the system board.
7. Reconnect all cables to their connectors at the back of the computer.
8. Replace the computer cover (see Replacing the Computer Cover).
9. Connect your computer and devices to electrical outlets, and turn them on.
Back to Contents Page
CAUTION: The processor package and heat-sink assembly can get hot. To avoid burns, ensure that the package and assembly have had sufficient
time to cool before you touch them.
