Because the door is captive, it will remain in the open position.
5. Remove the card:
a. If necessary, disconnect any cables connected to the card.
b. If the card is full-length, press the release tab on the end of the alignment guides on the fan case.
c. If the connector has a release tab, press the release tab as you grasp the card by its top corners, and ease it out of its connector.
6. If you are removing the card permanently, install a filler bracket in the empty card-slot opening.
7. Before you close the card retention door, ensure that:
l The tops of all cards and filler brackets are flush with the alignment bar.
l The notch in the top of each card or filler bracket fits around the alignment guide.
NOTE: Installing filler brackets over empty card-slot openings is necessary to maintain FCC certification of the computer. The brackets also keep dust
and dirt out of your computer.
