About your monitor
USB Type-A downstream connector
Figure 6. USB Type-A downstream connector
Table 17. Pin assignments - USB Type-A downstream connector
Pin number 9-pin side of the connector
1 VCC
2 D-
3 D+
4 GND
5 SSRX-
6 SSRX+
7 GND
8 SSTX-
9 SSTX+
