Setting up the monitor
Using the tilt, slant and height adjustment
NOTE: The following instructions are applicable only for attaching the stand that was shipped with your monitor. If you are
attaching a stand that you purchased from any other source, follow the setup instructions that were included with the stand.
Tilt and slant adjustment
With the stand attached to the monitor, you can tilt and slant the monitor for the most comfortable viewing angle.
-5
o
21
o
4
o
4
o
Figure 27. Tilt and slant adjustment
NOTE: The stand assembly is not pre-installed when the monitor is shipped from the factory.
Height adjustment
NOTE: The stand can extend vertically up to 130 mm.
The following image illustrates how to extend the stand vertically.
130 mm
Figure 28. Height adjustment
