Setting up the monitor
Wall mounting (optional)
Figure 26. Wall mounting
NOTE: Use M4 x 10 mm screws to connect the monitor to the wall mounting kit.
See the documentation that is shipped with the VESA-compatible wall mounting kit.
1.
Place the monitor panel on a soft cloth or cushion on a stable flat table.
2.
Remove the stand (see Removing the monitor stand).
3.
Using a Phillips crosshead screwdriver, remove the four screws securing the plastic cover.
4.
Attach the mounting bracket from the wall mounting kit to the monitor.
5.
Mount the monitor on the wall. For more information, see the documentation that is shipped with the wall mounting kit.
NOTE: Mount the monitor using only UL/CSA/GS-listed wall mount bracket with minimum weight or load-bearing capacity
(27.64 kg).
