Setting up the monitor
Routing the cables to side I/O (optional)
Figure 21. Routing the cables to side I/O
To route the cables to the side I/O:
1.
Insert the HDMI cable (purchased separately) and USB cable (purchased separately) into the side I/O connector.
2.
Insert and organize the cables under the restraint lever as shown above.
Attaching the side I/O-cover
Figure 22. Attaching the side I/O-cover
To attach the side I/O-cover:
1.
Align and place the tabs on the side I/O-cover with the slots on the display back-cover.
2.
Press the side I/O-cover to snap it into place.
Organizing your cables
Route the cables through the cable management guide on the stand riser.
Figure 23. Organizing your cables
After connecting all necessary cables to your monitor and computer, (see Connecting your monitor for cable attachment) organize
all cables as shown in the image.
If your cable is not able to reach your computer, you may connect directly to the computer without routing through the cable
management guide on the monitor stand.
