38
Operating the monitor
Using the joystick control
Use the joystick control on the rear of the monitor to make On-Screen Display (OSD) adjustments.
Figure 31. Using the joystick control
1.
Press the joystick to launch the Menu Launcher.
2.
Adjust the joystick in any direction-up, down, left, or right-to navigate through the options.
3.
Press the joystick again to confirm the selection.
Table 24. Using the joystick control
Joystick Description
When there is no OSD on the screen, press the joystick to launch the Menu Launcher. See
Accessing the Menu Launcher.
When the OSD is displayed, press the joystick to confirm the selection or save the settings.
For two way (right and left) directional navigation.
Move right to enter the submenu.
Move left to the upper-level menu or exit from the current menu.
For two way (up and down) directional navigation.
Navigates between the menu items.
Increases (up) or decreases (down) the parameters of selected menu item.
