Port LEDs
Gigabit Copper Ports
The following describes the LED indications for the Gigabit ports:
Table 3-2.
LED Color
LNK LED (Link/Speed)
Solid Green – Link at 1000Mbps
Solid Yellow Amber – Link at 10/100Mbps
OFF – No Link
Non-PoE Switch
ACT LED
Green Blinking – Activity
OFF – No activity
PoE Switch
PoE/ACT LED
Green Blinking – Activity, PoE power OFF
Amber Blinking – Activity, PoE power ON
Amber Solid – No Activity, PoE power ON
OFF – No Activity, PoE power OFF
