Dell X1000 Series User Manual

68 Dashboard
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Dell Astute\User
Guide\Dell_Astute_Dashboard.fm
DELL CONFIDENTIAL – PRELIMINARY 8/9/16 - FOR PROOF ONLY
The remaining fields on this page are display-only, and describe the port
configuration of the profile. The following fields are described:
Port Security fields:
– Mode — Learning mode. The possible options are:
•
Classic Lock — Locks the port using the classic lock mechanism.
The port is immediately locked, regardless of the number of
addresses that have already been learned.
•
Limited Dynamic Lock — Locks the port by deleting the
dynamic MAC addresses associated with the port. The port learns
up to the maximum addresses allowed on the port. Both
relearning and aging MAC addresses are enabled.
–
Max Entries — Displays the maximum number of MAC addresses
that can be learned on the port.
–
Action on Violation — Action to be applied to packets arriving on a
locked port. The possible options are:
•
Discard — Discard the packets from any unlearned source.
•
Forward — Forward the packets from an unknown source,
without learning the MAC address.
•
Shutdown — Discard the packet from any unlearned source, and
shut down the port. Ports remain shutdown until they are
reactivated, or the device is reset.
7 Click Next to view the configuration.
8 Click Apply to save the changes.
Initial Setup
NOTE: This feature removes any saved configurations.
To configure the device using this wizard:
1
Click Initial Setup .
2 Click Next .
3 Enter the IP Address Source . Select one of the following options:
–
Static IP — IP address manually selected.
–
Dynamic IP (DHCP) — IP address assigned by DHCP server.

Dell X1000 Series Specifications

General

PoE	No
Management	Unmanaged
Switching Capacity	16 Gbps (8-Port), 32 Gbps (16-Port)
Forwarding Rate	11.9 Mpps (8-Port), 23.8 Mpps (16-Port)
Jumbo Frame Support	9KB
Type	Unmanaged
Ports	8
Mounting	Desktop
MAC Address Table Size	8K
Power Consumption	8.5W (16-Port)
Series	X1000 Series
