AS Series Module Manual
5- 2
5.1 Overview
This chapter describes the specifications for the analog input/output module, its operation, and its
programming. On the analog input/output module, four channels receive analog signals (voltage or current),
and converts those signals into 16-bit digital signals. In addition, the analog input/output module receives two
blocks of 16-bit digital data from a CPU module, and converts the digital data into analog signals (voltage or
current). The analog input/output module sends the analog signals by two channels
5.1.1 Characteristics
(1) Use the AS06XA-A analog input/output module, based on its practical application.
CH1–CH4: A channel can receive either voltage or current inputs.
CH5–CH6: A channel can send either voltage or current outputs.
(2) High-speed conversion
The conversion rate is 2 ms per channel.
(3) High accuracy
Conversion accuracy: At ambient temperature of 25° C.
Input: The error range for both voltage and current input is ±0.2%.
Output: The error range for both voltage and current output is ±0.02%.
(4) Use the utility software to configure the module.
The HWCONFIG utility software is built into ISPSoft. You can set modes and parameters directly in
HWCONFIG without spending time writing programs to set registers to manage functions.
