13.2 Specification and Wiring
13.2.1 Specifications
 Unit Specification
Item Specifications
Module type
IO-Link master
Model name
AS04SIL-A
Number of IO-Link ports
4
Communication
Baud rate
4.8kbps, 38.4kbps,230.4kbps
Topology
1 : 1
Compliant
standards
 IO-Link Interface and System Specification Version 1.1.2

IO-Link Tester Specification Version 1.1.2
Mode
IO-Link
Yes
SIO (DI)
Yes
SIO (DO)
Yes, up to 100 mA / channel
Cyclic communications
Min. 2 ms; dynamic, according to the valid data length
Input: data size in each communication
port
Max. 32 bytes
Output: data size in each
communication port
Max. 32 bytes
Input: data size in each module
Max. 128 bytes
Output: data size in each module
Max. 128 bytes
Input PDO data size
Max. 100 words
Output PDO data size
Max. 100 words
Backup
Yes
Cable specification
Type
Unshielded (can also apply to shielded ones)
Length
Max. 20 m
Electrostatic
capacity
between lines
Max. 3 nF
Loop resistance
Max. 6 Ω
External connection terminals
Removable terminal block, clamping connector
