AS Series Module Manual
11-56
No. Name Unit Description
of analog I/O modules and temperature modules are determined by the
default mapping parameter length and user-added parameter length
together, no more than 20 words.
11.5.4.2. Introduction of Software
Before the new version of DeviceNet Builder software is used for making a connection with PLC, make sure that the
communication manager COMMGR has been installed.
(Refer to ISPSoft user manual for details on COMMGR usage.)
11.5.4.2.1. Making a connection between DeviceNet Builder and PLC
Before making a normal connection between DeviceNet Builder and PLC, you have to do relevant setup for COMMGR
software.
1. Build a driver through the COMMGR software.
Refer to Section 2.4 Communication Setting in the ISPSoft User Manual for more details.
2. Call DeviceNet Builder via ISPSoft
Refer to Section 11.6 for details on how to operate.
3. The called DeviceNet Builder is started as below.
To Next Page
