When AS01DNET is at different positions of the right of the PLC, the input and output mapping areas for the AS01DNET
module in AS PLC are listed in the following table.
Position of
AS01DNET on
the right of the
PLC
Output mapping area Input mapping area
1
D26100 – D26199 D26000 – D26099
2
D26500 – D26599 D26400 – D26499
3
D26900 – D26999 D26800 – D26899
4
D27300 – D27399 D27200 – D27299
11.4.3.2. Tables of Input Mapping and Output Mapping areas
 When AS01DNET works in master mode, the input and output mapping areas for AS01DNET at different
positions of the right of AS PLC are listed in the following table.
Position of
AS01DNET
on the right
of the PLC
Output mapping area (for sending data to
the slave)
Input mapping area (for receiving data from
the slave)
D register Mapping area
Data
size
D register Mapping area
Data
size
1
D26100~D26103
Bit-strobe
command area
4
words
D26000~D26003
Scan-list node
status indication
area
4
words
D26104 Reserved 1word D26004
Module status
indication area
1 word
D26105~D26199
DeviceNet
output data
area
95
words
D26005~D26099
DeviceNet input
data area
95
words
2
D26500~D26503
Bit-strobe
command area
4
words
D26400~D26403
Scan-list node
status indication
area
4
words
D26504 Reserved 1word D26404
Module status
indication area
1 word
D26505~D26599
DeviceNet
output data
area
95
words
D26405~D26499
DeviceNet input
data area
95
words
3
D26900~D26903
Bit-strobe
command area
4
words
D26800~D26803
Scan-list node
status indication
area
4
words
D26904 Reserved 1word D26804
Module status
indication area
1 word
D26905~D26999
DeviceNet
output data
area
95
words
D26805~D26899
DeviceNet input
data area
95
words
4
D27300~D27303
Bit-strobe
command area
4
words
D27200~D27203
Scan-list node
status indication
area
4
words
D27304 Reserved 1word D27204
Module status
indication area
1 word
D27305~D27399
DeviceNet
95
D27205~D27299
DeviceNet input
95
