3. Click Network >> Online to scan the connected master.
4. Clicking Network>> Scan DeviceNet Network, the DeviceNet Builder software starts to scan the whole network.
5. After scanning is finished, all node icons and device names which have been scanned in the network will appear
on the following interface. The node address of AS01DNET-A is 00 in this example.
