AS Series Module Manual
11-52
11
11.5.2 AS-Series Extension Modules Connectable to AS01DNET (RTU)
The model and specification of AS-series digital modules connectable to AS01DNET (in RTU mode):
Digital I/O module
model
Length of I/O mapping data (Unit: words)
（Master→AS01DNET） （AS01DNET→Master）
AS08AM10N-A
None 1
AS16AM10N-A
None
1
AS32AM10N-A
None
2
AS64AM10N-A
None 4
AS08AN01T-A
1
None
AS08AN01R-A
1
None
AS08AN01P-A
1
None
AS16AN01T-A
1
None
AS16AN01R-A
1
None
AS16AN01P-A
1
None
AS32AN02T-A
2
None
AS64AN02T-A
4
None
AS16AP11T-A
1 1
AS16AP11R-A
1 1
AS16AP11P-A
1 1
The model and specification of AS-series special modules connectable to AS01DNET (in RTU mode):
Special module model
Length of I/O mapping data (Unit: words)
DeviceNet→AS01DNET(RTU) AS01DNET(RTU)→DeviceNet
AS04AD-A
6 None
AS04DA-A
2 4
AS06XA-A
10 4
AS02LC-A
7 1
AS04RTD-A
10 None
AS06RTD-A
14 None
AS04TC-A
10
None
AS08TC-A
18
None
AS08AD-B
18 None
AS08AD-C
18 None
Note:
The length of mapping data of the I/O modules connected to AS01DNET (in RTU mode) is fixed. The default mapping
parameters of special modules must be chosen.
Besides default mapping parameter configuration, you can also choose other parameters for I/O mapping according to
need when special modules are connected to AS01DNET (RTU). The max. input length and max. output length of
default parameters and user-added mapping parameters of each special module are both 20 words.
