Delta ASDA-B2-F Series User Manual

Parameters ASDA-B2-F
7-8 September, 2015
7
Planning of Digital Input / Output Pin and Output Setting Parameter
Parameter Abbr. Function Default Unit
Control Mode
Related
Section
DMC Sz Tz
P0-53 ZDRT
General Range Compare Digital Output
- Filtering Time
0 ms O O O -
P0-54 ZON1L
General Range Compare Digital Output
- Lower Limit of 1
st
Monitoring Variable
0 - O O O -
P0-55 ZON1H
General Range Compare Digital Output
- Upper Limit of 1
st
Monitoring Variable
0 - O O O -
P2-09 DRT DI Debouncing Time 2 ms O O O -
P2-10 DI1 DI1 Functional Planning 101 - O O O
Table
7.1
P2-11 DI2 DI2 Functional Planning 104 - O O O
Table
7.1
P2-12 DI3 DI3 Functional Planning 022 - O O O
Table
7.1
P2-13 DI4 DI4 Functional Planning 023 - O O O
Table
7.1
P2-14 DI5 DI5 Functional Planning 021 - O O O
Table
7.1
P2-18 DO1 DO1 Functional Planning 101 - O O O
Table
7.2
P2-19 DO2 DO2 Functional Planning 103 - O O O
Table
7.2
P1-38 ZSPD Zero Speed Range Setting
10.0
(Panel /
Software)
1 r/min
(Panel /
Software)
O O O
Table
7.2
100
(Commu-
nication)
0.1 r/min
(Commu-ni
cation)
P1-39 SSPD Target Speed Detection Level 3000 r/min O O O
Table
7.2
P1-42 MBT1 Enable Delay Time of Brake 0 ms O O O 6.5
P1-43 MBT2 Disable Delay Time of Brake 0 ms O O O 6.5
P1-47 SCPD Speed Reached (DO.SP_OK) Range 10 r/min O -
P1-54 PER Position Completed Range 12800 pulse O
Table
7.2
P1-56 OVW Output Overload Warning Level 120 % O O O -
Communication Parameter
Parameter Abbr. Function Default Unit
Control Mode
Related
Section
DMC Sz Tz
P3-00● ADR Address Setting 01 - O O O -
P3-01 BRT Transmission Speed 3203 bps O O O -
P3-02 PTL Communication Protocol 6 - O O O -
P3-03 FLT Communication Error Disposal 0 - O O O -
P3-04 CWD Communication Timeout 0 sec O O O -
