Delta ASDA-B2-F Series User Manual

ASDA-B2-F Parameters
September, 2015 7-9
7
P3-05 CMM Communication Mechanism 0 - O O O -
P3-06■ SDI Control Switch of Digital Input (DI) 0 - O O O -
P3-07 CDT Communication Response Delay Time 0 0.5 ms O O O -
P3-08 MNS Monitor Mode 0 - O O O -
P3-09 SYC DMCNET Synchronize Setting 3511 - O -
P3-10 CANEN DMCNET Protocol Setting 1 - O -
P3-11 CANOP DMCNET Selection 0 - O -
P3-12 QSTPO DMCNET Support Setting 0 - O -
(★) Read-only register, can only read the status. For example: P0-00, P0-10 and P4-00, etc.
(▲) Setting is invalid when Servo On, e.g. P1-00, P1-46 and P2-33, etc.
( ● ) Not effective until re-power on or off the servo drive, e.g. P1-01 and P3-00.
( ■ ) Parameters of no data retained setting, e.g. P2-31 and P3-06.
Diagnosis Parameter
Parameter Abbr. Function Default Unit
Control Mode
Related
Section
DMC Sz Tz
P4-00★
ASH1 Fault Record (N) 0 - O O O 4.4.1
P4-01★
ASH2 Fault Record (N-1) 0 - O O O
4.4.1
P4-02★
ASH3 Fault Record (N-2) 0 - O O O
4.4.1
P4-03★
ASH4 Fault Record (N-3) 0 - O O O
4.4.1
P4-04★
ASH5 Fault Record (N-4) 0 - O O O
4.4.1
P4-05 JOG Servo Motor Jog Control 20 r/min O O O 4.4.2
P4-06▲■ FOT
Digital Output Register
(Readable and Writable)
0 - O O O 4.4.3
P4-07 ITST Multi-function of Digital Input 0 - O O O
4.4.4
8.2
P4-08★
PKEY
Input Status of the Drive Keypad
(Read-only)
- - O O O -
P4-09★
MOT Digital Output Status (Read-only) - - O O O 4.4.5
P4-10▲ CEN Adjustment Selection 0 - O O O -
P4-15 COF1
Current Detector (V1 Phase) Offset
Adjustment
Factory
Setting
- O O O -
P4-16 COF2
Current Detector (V2 Phase) Offset
Adjustment
Factory
Setting
- O O O -
P4-17 COF3
Current Detector (W1 Phase) Offset
Adjustment
Factory
Setting
- O O O -
P4-18 COF4
Current Detector (W2 Phase) Offset
Adjustment
Factory
Setting
- O O O -
P4-19 TIGB
IGBT NTC Adjustment Detection Level
(cannot reset)
Factory
Setting
- O O O -
