Delta ASDA-B2-F Series

Parameters ASDA-B2-F
7-12 September, 2015
7
P0-03~P0-07 Reserved
P0-08★
TSON Power On Time
A
ddress: 0010H
0011H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 0
Control
Mode:
-
Unit: Hour Range: 0 ~ 65535
Format: DEC Data Size: 16-bit
Settings:
It shows the total start up time of the servo drive.
P0-09★
CM1 Status Monitor Register 1
A
ddress: 0012H
0013H
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: -
Control
Mode:
ALL
Unit: - Range: -
Format: DEC Data Size: 32-bit
Settings:
The setting value which is set by P0-17 should be monitored via P0-09. (Please refer to P0-02).
Users need to access the address via communication port to read the status.
For example:
If P0-17 is set to 3, when accessing P0-09, it obtains the total feedback pulse number of motor
encoder. For MODBUS communication, two 16-bit data, 0012H and 0013H will be read as one
32-bit data; (0013H:0012H) = (Hi-word:Low-word) Set P0-02 to 23. The panel displays “VAR-1”
first, and then shows the content of P0-09.
P0-10★
CM2 Status Monitor Register 2
A
ddress: 0014H
0015H
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: -
Control
Mode:
ALL
Unit: - Range: -
Format: DEC Data Size: 32-bit
Settings:
The setting value which is set by P0-18 should be monitored via P0-10. (Please refer to P0-02)
Users need to access the address via communication port to read the status. Set P0-02 to 24. The
panel displays “VAR-2” first, and then shows the content of P0-10.
P0-11★
CM3 Status Monitor Register 3
A
ddress: 0016H
0017H
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: -
Control
Mode:
ALL
Unit: - Range: -
Format: DEC Data Size: 32-bit
Settings:
The setting value which is set by P0-19 should be monitored via P0-11. (Please refer to P0-02)
Users need to access the address via communication port to read the status. Set P0-02 to 25. The
panel displays ‟VAR-3” first, and then shows the content of P0-11.
P0-12★
CM4 Status Monitor Register 4
A
ddress: 0018H
0019H
Operational
Interface:
Panel / Software Communication
Related
Section:
3.3.5
Default: -
Control
Mode:
ALL
Unit: - Range: -
Format: DEC Data Size: 32-bit
Settings:
