Delta ASDA-B2-F Series User Manual

ASDA-B2-F Parameters
September, 2015 7-45
7
P2-35 PDEV
Condition of Excessive Position Control
Deviation Warning
A
ddress: 0246H
0247H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 3840000
Control
Mode:
DMCNET
Unit: Pulse Range: 1 ~ 128000000
Format: DEC Data Size: 32-bit
Settings:
It is the setting of excessive position control deviation warning in servo drive error display (P0-01).
P2-36~P2-42 Reserved
P2-43 NCF2 Resonance Suppression (Notch Filter) (2)
A
ddress: 0256H
0257H
Operational
Interface:
Panel / Software Communication
Related
Section:
6.3.6
Default: 1000
Control
Mode:
ALL
Unit: Hz Range: 50 ~ 2000
Format: DEC Data Size: 16-bit
Settings:
The second setting value of resonance frequency. If P2-44 is set to 0, this function is disabled.
P2-23 and P2-24 are the first group of notch filter.
P2-44 DPH2
Resonance Suppression (Notch Filter)
Attenuation Rate (2)
A
ddress: 0258H
0259H
Operational
Interface:
Panel / Software Communication
Related
Section:
6.3.6
Default: 0
Control
Mode:
ALL
Unit: -dB Range:
0 ~ 32 (0: Disable the function of
notch filter)
Format: DEC Data Size: 16-bit
Settings:
The second resonance suppression (notch filter) attenuation rate. When this parameter is set to 0,
the function of notch filter is disabled.
Note:
If the value of attenuation rate is set to 5, then, it would be -5 dB.
P2-45 NCF3 Resonance Suppression (Notch Filter) (3)
A
ddress: 025AH
025BH
Operational
Interface:
Panel / Software Communication
Related
Section:
6.3.6
Default: 1000
Control
Mode:
ALL
Unit: Hz Range: 50 ~ 2000
Format: DEC Data Size: 16-bit
Settings:
The third setting value of resonance frequency. If P2-46 is set to 0, this function is disabled. P2-23
and P2-24 are the first group of notch filter.
P2-46 DPH3
Resonance Suppression (Notch Filter)
Attenuation Rate (3)
A
ddress: 025CH
025DH
Operational
Interface:
Panel / Software Communication
Related
Section:
6.3.6
Default: 0
Control
Mode:
ALL
Unit: -dB Range: 0 ~ 32
Format: DEC Data Size: 16-bit
Settings:
The third resonance suppression (notch filter) attenuation rate. When this parameter is set to 0, the
function of notch filter is disabled. If the value of attenuation rate is set to 5, then, it would be -5 dB.
