Parameters ASDA-B2-F
7-46 September, 2015
7
P2-47 ANCF Auto Resonance Suppression Mode Setting
ddress: 025EH
025FH
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 1
Control
Mode:
ALL
Unit: - Range: 0 ~ 2
Format: DEC Data Size: 16-bit
Settings:
0: The auto-detection function is disabled.
1: Set back to 0 after resonance suppression.
2: Continuous resonance suppression.
Description of Auto Mode Setting:
When it is set to 1: Auto resonance suppression. The value returns to 0 automatically and the point
of resonance suppression will be saved automatically when the estimation is stable. If it is unstable,
re-power on or set back to 1 for re-estimation.
When it is set to 2: Continuous auto resonance suppression. When the estimation is stable, the
point of resonance suppression will be saved automatically. If it is unstable, re-power on for
re-estimation.
When switching to mode 0 from mode 2 or 1, the setting of P2-43, P2-44, P2-45 and P2-46 will be
saved automatically.
P2-48 ANCL Resonance Suppression Detection Level
ddress: 0260H
0261H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 100
Control
Mode:
ALL
Unit: - Range: 1 ~ 300 %
Format: DEC Data Size: 16-bit
Settings:
(The smaller the setting value is, the more sensitive toward the resonance will be.)
P2-48↑, resonance sensitiveness↓
P2-48↓, resonance sensitiveness↑
P2-49 SJIT Speed Detection Filter
ddress: 0262H
0263H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 0B
Control
Mode:
ALL
Unit: - Range: 0x00 ~ 0x1F
Format: HEX Data Size: 16-bit
Settings:
The filter of speed estimation
Setting
Value
Speed Estimation
Bandwidth (Hz)
Setting
Value
Speed Estimation
Bandwidth (Hz)
00 2500
10 750
01 2250
11 700
02 2100
12 650
03 2000
13 600
04 1800
14 550
05 1600 15 500
06 1500 16 450
07 1400 17 400
08 1300 18 350
09 1200 19 300
0A 1100 1A 250
0B 1000 1B 200
