Delta ASDA-B2-F Series User Manual

Parameters ASDA-B2-F
7-58 September, 2015
7
P4-16 COF2 Current Detector (V2 Phase) Offset Adjustment
A
ddress: 0420H
0421H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: Factory default
Control
Mode:
ALL
Unit: - Range: 0 ~ 32767
Format: DEC Data Size: 16-bit
Settings:
Manually adjust the hardware offset. The adjustment function needs to be enabled by the setting of
parameter P2-08. It is not suggested to adjust the auxiliary adjustment. This parameter cannot be
reset.
P4-17 COF3 Current Detector (W1 Phase) Offset Adjustment
A
ddress: 0422H
0423H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: Factory default
Control
Mode:
ALL
Unit: - Range: 0 ~ 32767
Format: DEC Data Size: 16-bit
Settings:
Manually adjust the hardware offset. The adjustment function needs to be enabled by the setting of
parameter P2-08. It is not suggested to adjust the auxiliary adjustment. This parameter cannot be
reset.
P4-18 COF4 Current Detector (W2 Phase) Offset Adjustment
A
ddress: 0424H
0425H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: Factory default
Control
Mode:
ALL
Unit: - Range: 0 ~ 32767
Format: DEC Data Size: 16-bit
Settings:
Manually adjust the hardware offset. The adjustment function needs to be enabled by the setting of
parameter P2-08. It is not suggested to adjust the auxiliary adjustment. This parameter cannot be
reset.
P4-19 TIGB
IGBT NTC Adjustment Detection Level (cannot
reset)
A
ddress: 0426H
0427H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: Factory default
Control
Mode:
ALL
Unit: - Range: 1 ~ 4
Format: DEC Data Size: 16-bit
Settings:
Please cool down the drive to 25°C when adjusting.
P4-20~P4-23 Reserved
P4-24 LVL Level of Under Voltage Error
A
ddress: 0430H
0431H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 160
Control
Mode:
ALL
Unit: V (rms) Range: 140 ~ 190
Format: DEC Data Size: 16-bit
Settings:
When the voltage of DC BUS is lower than P4-24* 2 , the under voltage error occurs.
