Chapter 7 Optional AccessoriesC2000
7-18
Unit: mm
Model
Input AC reactor
Delta part #
A B C D1*D2 H G G1 Q M PE D
VFD185C43A
DR038AP639 180 195 160 6*12 115 85 122 16 1.2~1.4 M4
VFD220C43A
DR045AP541 235 235 145 7*13 85 / 176 16 1.2~1.4 M6
Table 7-24
