Chapter 12 Description of Parameter SettingsC2000
12.1-00-1
Chapter 12 Description of Parameter Settings
12-1 Description of Parameter Settings
00 Drive Parameters
 You can set this parameter during operation.
Identity Code of the AC Motor Drive
Default: #.#
Settings Read Only
Display AC Motor Drive Rated Current
Default: #.#
Settings Read Only
 Pr. 00-00 displays the identity code of the AC motor drive. Use the following specification table to
check if Pr.00-01 setting is the rated current of the AC motor drive. Pr.00-01 corresponds to the
identity code of the AC motor drive (Pr. 00-00).
 The default is the rated current for normal load. Set Pr.00-16 to 1 to display the rated current for
heavy load.
230V Series
Frame A B C
kW 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
HP 1.0 2.0 3.0 5.0 7.5 10 15 20 25 30
Identity code 4 6 8 10 12 14 16 18 20 22
Rated current for
heavy load (A)
4.8 7.1 10 16 24 31 47 62 71 86
Rated current for
normal load (A)
5 8 11 17 25 33 49 65 75 90
Frame D E F
kW 30 37 45 55 75 90
HP 40 50 60 75 100 125
Identity code 24 26 28 30 32 34
Rated current for
heavy duty (A)
114 139 171 204 242 329
Rated current for
normal duty (A)
120 146 180 215 255 346
460V Series
Frame
A B C
kW 0.75 1.5 2.2 3.7 4.0 5.5 7.5 11 15 18.5 22 30
HP 1 2 3 5 5 7.5 10 15 20 25 30 40
Identity code 5 7 9 11 93 13 15 17 19 21 23 25
Rated current for
heavy load (A)
2.9 3.8 5.7 8.1 9.5 11 17 23 30 36 43 57
Rated current for
normal load (A)
3.0 4.0 6.0 9.0 10.5 12 18 24 32 38 45 60
Frame D0 D E F G H
kW 37 45 55 75 90 110 132 160 185 220 280 315 355 450
HP 50 60 75 100 125 150 175 215 250 300 375 425 475 600
Identity code 27 29 31 33 35 37 39 41 43 45 47 49 51 55
Rated current for
heavy load (A)
69 86 105 143 171 209 247 295 352 437 523 585 649 816
Rated current for
normal load (A)
73 91 110 150 180 220 260 310 370 460 550 616 683 866
