Chapter 11 Summary of Parameter SettingsC2000
11-42
09 Communication Parameters
Pr. Parameter Name Setting Range Default
09-00 Communication address 1–254
1
09-01 COM1 transmission speed 4.8–115.2Kbps 9.6
09-02 COM1 transmission fault treatment
0: Warn and continue operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning and continue operation
3
09-03 COM1 time-out detection 0.0–100.0 sec. 0.0
09-04 COM1 communication protocol
1 : 7, N, 2 (ASCII)
2 : 7, E, 1 (ASCII)
3 : 7, O, 1 (ASCII)
4 : 7, E, 2 (ASCII)
5 : 7, O, 2 (ASCII)
6 : 8, N, 1 (ASCII)
7 : 8, N, 2 (ASCII)
8 : 8, E, 1 (ASCII)
9 : 8, O, 1 (ASCII)
10 : 8, E, 2 (ASCII)
11 : 8, O, 2 (ASCII)
12: 8, N, 1 (RTU)
13: 8, N, 2 (RTU)
14: 8, E, 1 (RTU)
15: 8, O, 1 (RTU)
16: 8, E, 2 (RTU)
17: 8, O, 2 (RTU)
1
09-09 Communication response delay time 0.0–200.0ms 2.0
09-10 Communication main frequency 0.00–599.00Hz 60.00
09-11 Block transfer 1 0000–FFFFh 0000h
09-12 Block transfer 2 0000–FFFFh 0000h
09-13 Block transfer 3 0000–FFFFh 0000h
09-14 Block transfer 4 0000–FFFFh 0000h
09-15 Block transfer 5 0000–FFFFh 0000h
09-16 Block transfer 6 0000–FFFFh 0000h
09-17 Block transfer 7 0000–FFFFh 0000h
09-18 Block transfer 8 0000–FFFFh 0000h
09-19 Block transfer 9 0000–FFFFh 0000h
09-20 Block transfer 10 0000–FFFFh 0000h
09-21 Block transfer 11 0000–FFFFh 0000h
09-22 Block transfer 12 0000–FFFFh 0000h
