Delta C2000 Series User Manual

Chapter 12 Description of Parameter SettingsC2000
12.1-13-1
13 Application Parameters by Industry
 This parameter can be set during operation.
Application Selection
Default: 0
Settings 0: Disabled
1: User-defined Parameter
2: Compressor (IM)
3: Fan
4: Pump
10: Air Handling Unit, AHU
 Note: after you select the macro, some of the default values adjust automatically according to
the application selection.
 Group setting 02: Compressor (IM)
The following table lists the relevant compressor application parameters.
Pr. Explanation Settings
00-11 Speed control mode 0 (V/F control)
00-16 Load selection 0 (Normal load)
00-17 Carrier frequency Default setting
00-20
Master frequency command source (AUTO)
/ Source selection of the PID target
2 (External analog input)
00-21 Operation command source (AUTO) 1 (External terminals)
00-22 Stop method 0 (Ramp to stop)
00-23 Control of motor direction 1 (Disable reverse)
01-00 Maximum operation frequency Default setting
01-01 Output frequency of motor 1 Default setting
01-02 Output voltage of motor 1 Default setting
01-03 Mid-point frequency 1 of motor 1 Default setting
01-04 Mid-point voltage 1 of motor 1 Default setting
01-05 Mid-point frequency 2 of motor 1 Default setting
01-06 Mid-point voltage 2 of motor 1 Default setting
01-07 Minimum output frequency of motor 1 Default setting
01-08 Minimum output voltage of motor 1 Default setting
01-11 Output frequency lower limit 20 (Hz)
01-12 Acceleration time 1 20 (s)
01-13 Deceleration time 1 20 (s)
03-00 Analog input selection (AVI) 0 (No function)
03-01 Analog input selection (ACI) 1 (Frequency command)
05-01 Full-load current for induction motor 1 (A) Default setting
05-03 Rated speed for induction motor 1 (rpm) Default setting
05-04 Number of poles for induction motor 1 Default setting
