Chapter 12 Description of Parameter SettingsC2000
12.1-13-2
Group setting 03: Fan
The following table lists the relevant fan setting application parameters.
Pr. Explanation Settings
00-11 Speed control mode 0 (V/F control)
00-16 Load selection 0 (Normal load)
00-17 Carrier frequency Default setting
00-20
Master frequency command source (AUTO)
/ Source selection of the PID target
2 (External analog input)
00-21 Operation command source (AUTO) 1 (External terminals)
00-22 Stop method 1 (Coast to stop)
00-23 Control of motor direction 1 (Disable reverse)
00-30 Master frequency command (HAND) source 0 (Digital keypad)
00-31 Operation Command (HAND) source 0 (Digital keypad)
01-00 Maximum operation frequency Default setting
01-01 Output frequency of motor 1 Default setting
01-02 Output voltage of motor 1 Default setting
01-03 Mid-point frequency 1 of motor 1 Default setting
01-04 Mid-point voltage 1 of motor 1 Default setting
01-05 Mid-point frequency 2 of motor 1 Default setting
01-06 Mid-point voltage 2 of motor 1 Default setting
01-07 Minimum output frequency of motor 1 Default setting
01-08 Minimum output voltage of motor 1 Default setting
01-10 Output frequency upper limit 50 (Hz)
01-11 Output frequency lower limit 35 (Hz)
01-12 Acceleration time 1 15 (s)
01-13 Deceleration time 1 15 (s)
01-43 V/F curve selection 2 (Second V/F curve)
02-05 Multi-function input command 5 (MI5) 16 (Rotating speed command from ACI)
03-00 Analog input selection (AVI)
1 (Frequency command)
03-01 Analog input selection (ACI) 1 (Frequency command)
03-28 AVI terminal input selection 0 (0–10 V)
03-29 ACI terminal input selection 1 (0–10 V)
03-31 AFM output selection 0 (0–10 V)
03-50 Analog input curve selection 1 (three-point curve of AVI)
07-06 Restart after momentary power loss
2 (Speed tracking by minimum output
frequency)
07-11 Number of times of restart after fault 5 (times)
07-33 Auto-restart interval of fault 60 (s)
