7-6 EMC Filter
Following table is the external EMC filter of C2000 series, user can choose corresponding zero phase
reactor and suitable shielded cable length in accord to required noise emission and electromagnetic
interference level to have the best configuration to suppress the electromagnetic interference. When the
application does not consider RE and only needs CE to comply with C2 or C1, there is no need to install
zero phase reactor in input side.
230V model
C2000
Filter model name
Zero phase reactor
Fc
Conducted
Emission
Radiation
Emission
Frame Model
Rated input
current [A]
Input side
(R/S/T)
Output side
(U/V/W)
Output
shielded
cable length
EN61800-3
C2 C1
A
VFD007C23A 6.4
EMF021A23A
RF008X00A
or
T60006L2040W453
RF008X00A
or
T60006L2040W453
≤ 8kHz
100m 50m C2
VFD015C23A 12
VFD022C23A 16
VFD037C23A 20
B
VFD055C23A 28
EMF056A23A
RF004X00A
or
T60006L2050W565
RF004X00A
or
T60006L2050W565
VFD075C23A 36
VFD110C23A 52
C
VFD150C23A 72
KMF3100A
RF002X00A
or
T60006L2160V066
RF002X00A
or
T60006L2160V066
≤ 6kHz
VFD185C23A 83
VFD220C23A 99
D
VFD300C23A 124
B84143D0150R127 N/A
VFD370C23A 143
E
VFD450C23A 171
B84143B0250S020
N/A
RF300X00A
or
T60006L2160V066
≤ 4kHz
VFD550C23A 206
VFD750C23A 245
F VFD900C23A 331 B84143B0400S020
Table 7-59
