Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-51
460V model
C2000
Filter model name
(U/V/W)
Zero phase reactor
Fc
Conducted
Emission
Radiation
Emission
Frame Model
Rated
input
current
[A]
Input side
(R/S/T)
Output side
(U/V/W)
Output
shielded
cable length
EN61800-3
C2 C1
A
VFD007C43A 4.3
EMF014A43A
RF008X00A
or
T60006L2040W453
RF008X00A
or
T60006L2040W453
≤ 8kHz
100m 50m C2
VFD015C43A 5.9
VFD022C43A 8.7
VFD037C43A 14
EMF018A43A
VFD040C43A 15.5
VFD055C43A 17
B
VFD075C43A 20
EMF039A43A
RF004X00A
or
T60006L2050W565
RF004X00A
or
T60006L2050W565
VFD110C43A 26
VFD150C43A 35
C
VFD185C43A 40
KMF370A
RF002X00A
or
T60006L2160V066
RF002X00A
or
T60006L2160V066
≤ 6kHz
VFD220C43A 47
VFD300C43A 63
D0
VFD370C43S/U 74
B84143D0150R127
N/A
VFD450C43S/U 101
D
VFD550C43A 114
VFD750C43A 157
≤ 4kHz
E
VFD900C43A 167
B84143D0200R127
N/A
RF300X00A
or
T60006L2160V066
VFD1100C43A 207
F
VFD1320C43A 240
MIF3400B
VFD1600C43A 300
G
VFD1850C43A 380
VFD2200C43A 400
H
VFD2800C43A 494
MIF3800
VFD3150C43A 555
VFD3550C43A 625
VFD4500C43A 866 B84143B1000S020
C2000
Filter model name
(U/V/W)
Zero phase reactor
Carrier
Frequency
Conducted
Emission
Radiation
Emission
Frame Model
Rated Input
Current
[A]
Input
side
(R/S/T)
Output side
(U/V/W)
Output shielded
cable length
EN61800-3
EN618000-3 C2
D0
VFD370C43S/U 74
B84143B0120R110
N/A
N/A ≤6kHz 25m *C2
VFD450C43S/U 101
D
VFD550C43A 114
B84143B0180S020
RF300X00A
or
T60006L2160V066
≤4kHz
13m
*C3
VFD750C43A 157
E
VFD900C43A 167
B84143B0250S020
C2
VFD1100C43A 207
F
VFD1320C43A 240
B84143B0400S020
VFD1600C43A 300
G
VFD1850C43A 380
B84143B0600S020
≤2kHz
VFD2200C43A 400
H
VFD2800C43A 494
B84143B1000S020 *C3
VFD3150C43A 555
VFD3550C43A 625
VFD4500C43A 866
*For Radiated Emission, the drive needs to be placed inside a cabinet.
Table 7-60
