Chapter 9 Specification C2000
9-2
9-1 230V Series
Frame Size A B C D E F
Model VFD-_ _ _C_ _
007 015 022 037 055 075 110 150 185 220 300 370 450 550 750 900
*Output Rating
Normal Duty
Rated Output Capacity [kVA] 2.0 3.2 4.4 6.8 10 13 20 26 30 36 48 58 72 86 102 138
Rated Output Current [A] 5 8 11 17 25 33 49 65 75 90 120 146 180 215 255 346
Applicable Motor Output [kW] 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90
Applicable Motor Output [HP] 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 120
Overload Capacity
120% of rated output current: 1 minute for every 5 minutes;
160% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency [Hz] 0.00~599.00
Carrier Frequency [kHz] 2~15 (Default: 8) 2~10 (Default: 6) 2~9 (Default: 4)
Heavy Duty
Rated Output Capacity [kVA] 1.9 2.8 4.0 6.4 9.6 12 19 25 28 34 45 55 68 81 96 131
Rated Output Current [A] 4.8 7.1 10 16 24 31 47 62 71 86 114 139 171 204 242 329
Applicable Motor Output [kW] 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 19 22 30 37 45 55 75
Applicable Motor Output [HP] 0.5 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100
Overload Capacity
150% of rated output current: 1 minute for every 5 minutes;
180% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency [Hz] 0.00~300.00
Carrier Frequency [kHz] 2~15 (Default: 2) 2~10 (Default: 2) 2~9 (Default: 2)
Rating Input
Input Current [A]
Normal Duty 6.4 12 16 20 28 36 52 72 83 99 124 143 171 206 245 331
Heavy Duty 6.1 11 15 18.5 26 34 50 68 78 95 118 136 162 196 233 315
Rated Voltage / Frequency 3-phase AC 200V~240V (-15% ~ +10%)，50 / 60Hz
Operating Voltage Range 170~264V
AC
Frequency Tolerance 47~63Hz
Efficiency [%] 97.8 98.2
Power Factor >0.98
Drive Weight [Kg] 2.6 ± 0.3 5.4 ± 1 9.8 ± 1.5 38.5 ± 1.5 64.8 ± 1.5 86.5 ± 1.5
Cooling Method
Natural
cooling
Fan cooling
Braking Chopper Frame A~C: Built-in Frame D~F: Optional
DC choke Frame A~C: Optional Frame D~F: Built-in
EMC Filter Frame A~F: Optional
EMC-COP01 Frame A~F: Optional
Table 9-1
NOTE
1. * : The factory setting is Normal Duty mode.
2. The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Please refer to Chapter 9-7
Derating Curve of Ambient Temperature.
3. The AC motor drive should operate in derating current when its control method is set to FOC Sensorless, TQC+PG, TQC
sensorless. PM+PG, PM sensorless Please refer to Pr. 06-55 for more information.
4. Select the AC motor drive with capacity one grade larger for the impact load application.
5. The rated input current will be affected by not only Power Transformer and the connection of the reactors on input side, but
also fluctuates with the impedance of power side.
6. For Frame D and above, if the last character of the model is A then it is under IP20 protection level but the wiring terminal is
under IP00 protection level; if the last character of the model is E, it is under IP20/NEMA1/UL TYPE1 protection level.
