Chapter 12 Description of Parameter SettingsC2000

12.1-13-3

 Group setting 04: Pump

The following table lists the relevant pump setting application parameters.

Pr. Explanation Settings

00-11 Speed control mode 0 (V/F control)

00-16 Load Selection 0 (Normal load)

00-20

Master frequency command source (AUTO)

/ Source selection of the PID target

2 (External analog input)

00-21 Operation command source (AUTO) 1 (External terminals)

00-23 Control of motor direction 1 (Disable reverse)

01-00 Maximum operation frequency Default setting

01-01 Output frequency of motor 1 Default setting

01-02 Output voltage of motor 1 Default setting

01-03 Mid-point frequency 1 of motor 1 Default setting

01-04 Mid-point voltage 1 of motor 1 Default setting

01-05 Mid-point frequency 2 of motor 1 Default setting

01-06 Mid-point voltage 2 of motor 1 Default setting

01-07 Minimum output frequency of motor 1 Default setting

01-08 Minimum output voltage of motor 1 Default setting

01-10 Output frequency upper limit 50 (Hz)

01-11 Output frequency lower limit 35 (Hz)

01-12 Acceleration time 1 15 (s)

01-13 Deceleration time 1 15 (s)

01-43 V/F curve selection 2 (Second V/F curve)

07-06 Restart after momentary power loss

2 (Speed tracking by minimum output

frequency)

07-11 Number of times of restart after fault 5

07-33 Auto-restart interval of fault 60 (s)
