Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-34
Model
Output AC reactor
Delta part #
A A1 B B1 B2 C C1 D1*D2 E G1 H M*T
VFD300C43A DR060AP405 240 228 215 44 170 163 110 7*13 152 176 97 20*3
VFD370C43S/U DR073AP334 250 235 235 44 186 174 115 11*18 160 190 124 20*3
VFD450C43S/U DR091AP267 250 240 235 44 186 174 115 11*18 160 190 124 20*3
VFD550C43A DR110AP221 270 260 245 50 192 175 115 10*18 176 200 106 20*3
Table 7-42

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
