Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-36
Model
Output AC reactor
Delta part #
A A1 B B1 B2 C C1 D1*D2 E G1 H M*T
VFD2200C43A DR460AP054 360 355 510 106 401 346 215 12*20 240 240 240 50*5
VFD2800C43A DR550AP044 360 355 510 106 401 358 220 12*20 240 240 250 50*5
VFD3150C43A DR616AP039 360 355 510 110 401 376 230 12*20 240 240 270 50*8
VFD3550C43A DR683AP036 360 355 510 110 401 396 240 12*20 240 240 290 50*8
VFD4500C43A DR866AP028 410 418 570 120 464 402 245 12*20 280 280 290 50*8
Table 7-44

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
