Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-44
7-5 Zero Phase Reactors
Reactor
model (Note)
Recommended Wire Size
Wiring
Method
Qty
Corresponding motor drives
RF008X00A ≤ 8 AWG ≤ 8.37 mm
2
Diagram A
1C*3
or
4C*1
VFD007C23A; VFD015C23A; VFD022C23A;
VFD037C23A; VFD007C43A; VFD015C43A;
VFD022C43A; VFD037C43A; VFD040C43A;
VFD055C43A; VFD015C53A-21;
VFD022C53A-21; VFD037C53A-21;
VFD055C53A-21; VFD075C53A-21,
VFD110C53A-21; VFD150C53A-21
T60006L2040W453 ≤ 8 AWG ≤ 8.37 mm
2
Diagram B
RF004X00A ≤ 1 AWG ≤ 42.41 mm
2
Diagram A
1C*3
or
4C*1
VFD055C23A; VFD075C23A; VFD110C23A;
VFD110C43A; VFD150C43A; VFD075C43A;
VFD110C43A; VFD150C43A
T60006L2050W565 ≤ 1 AWG ≤ 42.41mm
2
Diagram B
RF002X00A ≤ 600MCM ≤ 304 mm
2
Diagram A
1C*3
or
4C*1
VFD150C23A; VFD185C23A;
VFD220C23A; VFD300C23A;
VFD370C23A; VFD450C23A;
VFD550C23A; VFD750C23A;
VFD900C23A; VFD185C43A;
VFD220C43A; VFD300C43A;
VFD550C43A; VFD750C43A;
VFD900C43A; VFD1100C43A;
VFD1320C43A; VFD1600C43A;
VFD185C63B-21; VFD220C63B-21;
VFD300C63B-21; VFD370C63B-21;
VFD450C63B-XX; VFD550C63B-XX
T60006L2050W565 ≤ 600MCM ≤ 304 mm
2
Diagram B
RF300X00A ≤ 300 MCM ≤ 152 mm
2
Diagram A
1C*12
or
4C*3
VFD1850C43A; VFD2200C43A;
VFD2800C43A; VFD3150C43A;
VFD3550C43A; VFD4500C43A;
VFD750C63B-XX; VFD900C63B-XX;
VFD1100C63B-XX; VFD1320C63B-XX;
VFD1600C63B-XX; VFD2000C63B-XX;
VFD2500C63B-XX; VFD3150C63B-XX;
VFD4000C63B-XX; VFD4500C63B-XX;
VFD5600C63B-XX; VFD6300C63B-XX;
Note 1: *600V insulated cable wire
Note 2: Above table only considers the motor wire size
Note 3: For max. wiring quantity, please refer to Chapter 5 Main
Circuit Terminal.
Table 7-53

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
