Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-67
Following table is the suggested shielded cable length of EMC built-in models. User can choose
corresponding shielded cable length in accord to required noise emission and electromagnetic interference
level.
EMC built-in model
Rated
current
(ND)
Comply with EMC (IEC 61800-3)
Class C3
Comply with EMC (IEC 61800-3)
Class C2
Frame Model Shielded cable length Fc Shielded cable length Fc
A
VFD007C43E 4.3
30m
≤ 8kHz
10m
≤ 8kHz
VFD015C43E 5.9
VFD022C43E 8.7
VFD037C43E 14
VFD040C43E 15.5
VFD055C43E 17
B
VFD075C43E 20
VFD110C43E 26
VFD150C43E 35
C
VFD185C43E 40
≤ 6kHz ≤ 6kHz VFD220C43E 47
VFD300C43E 63
* Shielded cable length of Frame A should be no longer than 30m and Frame B, C no longer than 50m to prevent
cable length from being too long, which may cause built-in EMC filter malfunction due to overheat resulting from
leakage current and larger wires parasitic capacitance.
EMC Filter Installation
All electrical equipment, including AC motor drives, will generate high frequency/ low frequency noise
and will interfere with peripheral equipment by radiation or conduction when in operation. By using an EMC
filter with correct installation, much interference can be eliminated. It is recommended to use DELTA EMC
filter to have the best interference elimination performance.
We assure that it can comply with following rules when AC motor drive and EMC filter are installed and
wired according to user manual:
1. EN61000-6-4
2. EN61800-3: 1996
3. EN55011 (1991) Class A Group 1
General precaution
To ensure EMC filter can maximize the effect of suppressing the interference of AC motor drive, the
installation and wiring of AC motor drive should follow the user manual. In addition, be sure to observe the
following precautions:
1. EMC filter and AC motor drive should be installed on the same metal plate.
2. Please install AC motor drive on footprint EMC filter or install EMC filter as close as possible to the AC
motor drive.
3. Please wire as short as possible.
4. Metal plate should be grounded.
5. The cover of EMC filter and AC motor drive or grounding should be fixed on the metal plate and the
contact area should be as large as possible.
Table 7-64

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
