Chapter 1 IntroductionC2000
1-14
Frame D
D1: VFD300C23A; VFD370C23A; VFD550C43A; VFD750C43A; VFD450C63B-00; VFD550C63B-00
H3
D2
D
S2
D1
DETAIL A
(MOUNTING HOLE)
H1
S1
W1
SEE DETAIL B
W
SEE DETAIL A
DETAIL B
(MOUNTING HOLE)
H2
S1
Figure 1-20
Unit: mm [inch]
D1*: Flange mounting
Frame W H D W1 H1 H2 H3 D1* D2 S1 S2 Φ1 Φ2 Φ3
D1
330.0
[12.99]
-
275.0
[10.83]
285.0
[11.22]
550.0
[21.65]
525.0
[20.67]
492.0
[19.37]
107.2
[4.22]
16.0
[0.63]
11.0
[0.43]
18.0
[0.71]
- - -
See Detail A
See Detail B
Detail A
(Mounting Hole)
Detail B
(Mounting Hole)
