8-8 EMC-PG01O / EMC-PG02O -- PG card (Open collector)
8-8-1 Terminal descriptions
Set by Pr.10-00–10-02, Pr.10-16–10-18
Terminals Descriptions
PG1
VP
Output voltage for power: +5V/+12V5% (use FSW3 to switch +5V/+12V)
Max. output current: 200mA
DCM Common for power and signal
A1, /A1, B1,
/B1, Z1, /Z1
Encoder Input signal (Line Driver or Open Collector)
Open Collector Input Voltage: +5V–+24V (Note 1)
It can be 1-phase or 2-phase input.
EMC-PG01O Max. input frequency: 300kHz
EMC-PG02O Max. input frequency: 30kHz (Note 2)
PG2
A2, /A2,
B2, /B2
Pulse Input Signal (Line Driver or Open Collector)
Open Collector Input Voltage: +5–+24V (Note 1)
It can be 1-phase or 2-phase input.
EMC-PG01O Max. input frequency: 300kHz
EMC-PG02O Max. input frequency: 30kHz (Note 2)
PG OUT
V+, V+
Needs external power source for PG OUT circuit.
Input voltage of power: +7V – +24V
V-
Input voltage for the negative side
A/O, B/O, Z/O
PG Card Output signals has division frequency function: 1–255 times.
On the open collector’s output signal, add a high-pull resistor on the
external power V+–V- (e.g. power of PLC) to prevent the interference of
the receiving signal. Max. [Three pull-up resistor are included in the
package (1.8k/1W)] (Note 1)
EMC-PG01O Max. input frequency: 300kHz
EMC-PG02O Max. input frequency: 30kHz
Note 1: Open Collector application, input current 5–15mA to each set then each set needs one pull-up resistor.
If input voltage of open collector is 24V, the power of encoder needs to be connected externally. Please refer to
diagram 2 of PG1.
5V
Recommended pull-up resistor: above 100–220, 1/2W
12V
Recommended pull-up resistor: above 510–1.35k, 1/2W
24V
Recommended pull-up resistor: above 1.8k–3.3k, 1/2W
Note 2: If the required bandwidth is not over 30kHz at the application, it is recommended to use
EMC-PG02O/L (bandwidth 30kHz) to avoid interference.
