Chapter 3 UnpackingC2000
3-26
Frame F
Applicable models:
VFD900C23A; VFD1320C43A; VFD1600C43A;
VFD900C23E; VFD1320C43E; VFD1600C43E;
VFD1600C63B-00; VFD2000C63B-00;
VFD1600C63B-21; VFD2000C63B-21
F
Frame G
Applicable models:
VFD1850C43A; VFD2200C43A; VFD1850C43E;
VFD2200C43E; VFD2500C63B-00; VFD3150C63B-00;
VFD2500C63B-21; VFD3150C63B-21
G
Frame H
Applicable models:
VFD2800C43A; VFD3150C43A; VFD3550C43A;
VFD4500C43A; VFD2800C43E-1; VFD3150C43E-1;
VFD3550C43E-1; VFD4500C43E-1; VFD2800C43E;
VFD3150C43E; VFD3550C43E; VFD4500C43E;
VFD4000C63B-00; VFD4500C63B-00;
VFD5600C63B-00; VFD6300C63B-00
F
G
H
Figure 3-81
Figure 3-82
Figure 3-83
