Chapter 5 Main Circuit TerminalsC2000
5-11
Frame C
U/T1
+2/DC+
R/L1 V/T2
-/DC- +1/DC+
S/L2 W/T3
B1 B2
T/L3
If you install at Ta 50°C environment, please select copper wire with voltage rating 600V and
temperature resistant 75°C or 90°C.
If you install at Ta 50°C above environment, please select copper wire with voltage rating 600V and
temperature resistant at 90°C or above.
For VFD220C23A, if you insall at Ta 40°C above environment, please select copper wire with
voltage rating 600V and temperature resistant at 90°C or above.
For UL installation compliant, please use copper wires for installation, the wire gauge is based on
temperature resistant at 75°C which is requested and recommended from UL. Do not reduce the
wire gauge when using higher temperature wrie.
Wire fix to pole +2/DC+ and +1/DC+ with 90 kg-cm / [78.2 lb-in] / [8.83 Nm] (±10%)
Model Name
Main Circuit Terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, -/DC-,
+1/DC+, +2/DC+, B1, B2
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
Max. Wire Gauge Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
VFD150C23A
50mm
2
[1/0 AWG]
50 mm
2
[1/0 AWG]
M8
80kg-cm
[69.4 lb-in.]
[7.84Nm]
50 mm
2
[1/0 AWG] 25 mm
2
[4 AWG]
M8
80kg-cm
[69.4 lb-in.]
[7.84Nm]
VFD185C23A
VFD220C23A
VFD185C43A
25 mm
2
[4 AWG] 25 mm
2
[4 AWG]
16 mm
2
[6 AWG]
VFD220C43A
VFD300C43A 35 mm
2
[2 AWG]
35 mm
2
[2 AWG]
VFD185C43E
25 mm
2
[4 AWG] 25 mm
2
[4 AWG]
VFD220C43E
VFD300C43E 35 mm
2
[2 AWG]
35 mm
2
[2 AWG]
VFD185C63B-21 10 mm
2
[8 AWG] 10 mm
2
[8 AWG] 10 mm
2
[8 AWG]
VFD220C63B-21 16 mm
2
[6 AWG] 16 mm
2
[6 AWG]
16 mm
2
[6 AWG] VFD300C63B-21 25 mm
2
[4 AWG] 25 mm
2
[4 AWG]
VFD370C63B-21 35 mm
2
[2 AWG] 35 mm
2
[2 AWG]
To Next Page
