Chapter 11 Summary of Parameter SettingsME300
11-11
02 Digital Input / Output Parameters
Pr. Explanation Settings Default
02-00
Two-wire / Three-wire
operation control
0: No function
1: Two-wire mode 1, power on for operation control
(M1: FWD / STOP, M2: REV / STOP)
2: Two-wire mode 2, power on for operation control
(M1: RUN / STOP, M2: FWD / REV)
3: Three-wire, power on for operation control
(M1: RUN, M2: REV / FWD, M3: STOP)
4: Two-wire mode 1, Quick Start
(M1: FWD / STOP, M2: REV / STOP)
5: Two-wire mode 2, Quick Start
(M1: RUN / STOP, M2: FWD / REV)
6: Three-wire, Quick Start
(M1: RUN, M2: REV / FWD, M3: STOP)
IMPORTANT
1. In the fast start-up function, terminal output keeps
in the ready status, and the drive responds to the
command immediately.
2. When using Quick Start function, the output
terminals UVW are with driving voltages in order to
output and respond immediately if a Start
command is given. Do not touch the terminals or
modify the motor wiring to prevent electric shocks.
1
02-01
Multi-function input
command 1 (MI1)
0: No function
1: Multi-step speed command 1 / multi-step
position command 1
2: Multi-step speed command 2 / multi-step
position command 2
3: Multi-step speed command 3 / multi-step
position command 3
4: Multi-step speed command 4 / multi-step
position command 4
0
02-02
Multi-function input
command 2 (MI2)
0
02-03
Multi-function input
command 3 (MI3)
1
02-04
Multi-function input
command 4 (MI4)
2
02-05
Multi-function input
command 5 (MI5)
3
5: Reset
6: JOG operation
[by external control or KPC-CC01 (optional)]
7: Acceleration / deceleration speed inhibit
8: 1
st
and 2
nd
acceleration / deceleration time selection
9: 3
rd
and 4
th
acceleration / deceleration time selection
10: External Fault (EF) Input (Pr.07-20)
11: Base Block (B.B.) input from external
