Chapter 11 Summary of Parameter SettingsME300
11-13
Pr. Explanation Settings Default
99: Simple positioning stop by reverse limit

02-09
External terminal UP /
DOWN key mode
0: By the acceleration / deceleration time
1: Constant speed (Pr.02-10)
2: Pulse signal (Pr.02-10)
3: Curve
4: Step (Pr.02-10)
0

02-10
External terminal Constant
speed, acceleration /
deceleration speed of the
UP/DOWN key
0.001–1.000 Hz/ms 0.001

02-11
Multi-function input
response time
0.000–30.000 sec. 0.005

02-12
Multi-function input mode
selection
0000h–FFFFh (0: N.O.; 1: N.C.) 0000

02-13
Multi-function output 1
(RY1)
0: No function
1: Indication during RUN
11

02-16
Multi-function output 2
(MO1)
2: Operation speed reached
3: Desired frequency reached 1 (Pr.02-22)
0
4: Desired frequency reached 2 (Pr.02-24)
5: Zero speed (Frequency command)
6: Zero speed including STOP (Frequency command)
7: Over-torque 1 (Pr.06-06–06-08)
8: Over-torque 2 (Pr.06-09–06-11)
9: Drive is ready
10: Low voltage warning (Lv) (Pr.06-00)
11: Malfunction indication
13: Overheat warning (Pr.06-15)
14: Software brake signal indication (Pr.07-00)
15: PID feedback error (Pr.08-13, Pr.08-14)
16: Slip error (oSL)
17: Count value reached, does not return to 0
(Pr.02-20)
18: Count value reached, returns to 0 (Pr.02-19)
19: External interrupt B.B. input (Base Block)
20: Warning output
21: Over-voltage
22: Over-current stall prevention
23: Over-voltage stall prevention
24: Operation source
25: Forward command
