Chapter 11 Summary of Parameter SettingsME300
11-14
Pr. Explanation Settings Default
26: Reverse command
29: Output when frequency ≥ Pr.02-34
30: Output when frequency < Pr.02-34
31: Y-connection for the motor coil
32: Δ-connection for the motor coil
33: Zero speed (actual output frequency)
34: Zero speed including STOP (output frequency)
35: Error output selection 1 (Pr.06-23)
36: Error output selection 2 (Pr.06-24)
37: Error output selection 3 (Pr.06-25)
38: Error output selection 4 (Pr.06-26)
40: Speed reached (including STOP)
42: Crane function
43: Motor speed detection
44: Low current output (use with Pr.06-71–06-73)
45: UVW output electromagnetic valve switch
46: Master dEb output
51: Analog output control for RS-485 interface
53: Fire mode indication
67: Analog input level reached
69: Preheating output indication
75: Forward RUN status
76: Reverse RUN status
77: Program Running Indication
78: Program Step Completed Indication
79: Program Running Completed Indication
80: Program Running Paused Indication
81: Multi-pump system error display (only master)

02-18 Multi-function output direction 0000h–FFFFh (0: N.O.; 1: N.C.) 0000h

02-19
Terminal counting value
reached (returns to 0)
0–65500 0

02-20
Preliminary counting value
reached
(does not return to 0)
0–65500 0

02-22
Desired frequency reached
1
0.00–599.00 Hz
60.00/
50.00

02-23
The width of the desired
frequency reached 1
0.00–599.00 Hz 2.00

02-24
Desired frequency reached
2
0.00–599.00 Hz
60.00/
50.00
